Viega Megapress S

Whether thick or thin-walled, painted or galvanised, coated or black – steel pipes can be used in a wide range of applications, with long service lives and are particularly robust. So it is a good thing that Viega has come up with yet another genuinely innovative technology: Megapress S. This system means that steel pipes can now make economic sense in heating, cooling, fire protection or industrial plant applications.

The advantages of Megapress S

  • Megapress S XL for steel pipe sizes ½ inch to 4 inches
  • up to 80% less assembly time compared with welding (in respect of the connection technology)
  • FKM sealing element for operating temperatures to 140 °C
  • Viega Smart Connect Feature in all Megapress connectors, so that inadvertently unpressed connections show immediately in leakage tests
  • can be used for seamless, welded, black, galvanised, epoxy-resin-coated and industrially painted pipes according to DIN EN 10255 / DIN EN 10216-1 and DIN EN 10217-1
  • absolutely fire-safe, because neither flames nor fumes arise with cold press connecting technology
  • perfectly suited for use in industrial facilities such as cooling, heating, sprinkler or compressed air systems

The advantages of the Pressgun Press Booster

  • innovative force amplifier for Megapress XL-sizes 2½, 3 and 4 inches with integrated hinged adapter jaw
  • optimally dosed pressing force for maximum safety
  • low weight and a handy carrying strap make for good ergonomics and easy handling
  • can be used for all Viega press machines from type 2 to Pressgun 5 (not compatible with Pressgun Picco)
  • special spherical heads on the hinged adapter jaw ensure that there can be no confusion with other Viega press rings
  • long service interval thanks to Viega’s typical reliability and quality

Quick, clean, safe and completely weld-free.

Download

Megapress S Brochure

Size 2.8 MB | Type PDF
Download

BSRIA Time & Motion Study

Size 1.7 MB | Type PDF

Megapress

Find all information about Megapress in our product catalogue.

Viega Megapress S XL

Viega Megapress & Press-In Branch Connector
